Vise

This was for a 3D printing class. This device can be 100% printed (see links below) or you can buy some cheap all-thread and nuts at your local hardware store like I did. This vise can be configured in a lot of different ways. It can turn 360 degrees around while being extended out a few inches. The extender can be removed and the vise can then be placed straight up or on its side directly on the base and then each of these configurations can be rotated 360 degrees. Two knobs are included to lock the vise at whatever angle it desired. It can be locked at almost any angle (see pictures). ###Details: There is a large version and a small version of the vise. The large version is 200 mm wide for the largest dimension of any part. The small version is half the size of the large version in every dimension. The files are separated by name with "small_" appended to the filename on the small version. ###Parts List: 1/4 - 20 all-thread (I bought a rod about 20 inches long for $1.60) 1/4 - 20 nuts (10 per vise) (if you want to print everything you might try this ---> https://www.thingiverse.com/thing:125838 (all-thread) https://www.thingiverse.com/thing:2501430 (nuts) ) ###Printed Parts: ######Small Vise: * small_Vise_base2 - base with cylinder * small_Vise_bolt_tube - captive nut tapped in from the side (2 used) * small_vise_clampArm3 - the moving side of the clamp * small_Vise_sleevePads - removable jaws (2 used) * small_Vise_Lextender2 - an optional piece that allows the vise to swivel * small_Vise_main8 - the main part of the vise that can be mounted different ways (widened the hole for the clampArm to make it easier to assemble) * small_Vise_wheel3 - the wheel that opens and closes the vise * small_Vise_Knob - the knob used to lock the vise in place (2 used) * small_Vise_wheel2_washer - washer used to lock wheel to all thread ######Large Vise: * Vise_base2 - base with cylinder * Vise_bolt_tube - captive nut tapped in fr
